工作原理Working principle

◎压缩式检针机工作原理：产品(枕头、靠垫)的高度例如为300mm,它的填充材料为无纺棉等软性材料。通过检针机的上下输送带挤压把产品压低成100-150mm左右高度，再通过检针，达到理想的检测效果。(检针机的通过检测高度越低，则检测灵敏度越好)

O The working principle of the compression needle detector:the height of the product (pllow,cushion)is for example300mm,an t filing material issoft material such as non-woven cotton.The product is pressed down to a height ofabout 100-150mm through the upper and lower conveyorbelts ofthe needle detector,and then passed through theneedle detector to achieve the ideal detection effect.(Thelower the passing detection height oftheneedle detector.the better the detection sensitivity)

产品特点Characteristic

More flexible I More reliable I Inteligentize I Convenient management

更灵活|可靠性强|智能化|易管理

◎可将毛绒玩具、抱枕等棉絮填充物产品通过压缩装置将高度压缩至指定检测高度，有效提高产品检测精度。

◎独创的磁场均匀感应设计，适合各类产品检测需求。

◎全中文显示，薄膜开关，人机交互流畅易学，

◎智能化计数系统，合格不合格精准计数

◎数字式灵敏度调节

◎智能化位置显示系统，精确显示被检物位置。

O The ON-V720C-YS Compression Type needle detector can compressthe cotton wool filling products such as plush toys and pillows to aspecified detection height through a compression device,therebyeffectively improving product detection accuracy.

◎ Unique magnetic field uniform induction design,suitable for all kindsof product testing needs.

O FullChinese display screen,membrane switch,human-computerinteraction is fluently and easy to learn.

OIntelligent counting system,qualified and unqualified accurate count-ing.

◎Digital sensitivity adjustment

OIntelligent position display system can accurately display the positionof the object under inspection.
